Diamond Audio LOC24-4-Channel (2 in / 4 Out) Line-Output Converter

LOC24 - 4-Channel (2 IN / 4 OUT) Line-Output ConverterDiamond Audio’s line output converters serve as your integration ticket for a great-sounding audio system. Not only do these provide tremendous output voltage, but they also provide you with an assortment of various output controls. The load select feature offers flexible compatibility and prevents unwanted system noise. The LOC series line output converters are available as a 2-channel or 4-channel model.Specifications:4-Channel (2 IN / 4 OUT) Line-Output ConverterIdeal Interface for Adding an Aftermarket AmplifierSingle Dial, Precision Matched, Stereo & Level Gain AdjustmentUp to 40 Volts RMS High Level Input SensitivityUp to 9.5 Volts RMS Low-level RCA OutputSelectable 20Ω / 60Ω / 20KΩ Load Input ImpedanceSelectable GND / ISO / 200Ω Ground IsolationBass Boost: 0-12dBDimensions: 4.53" x 3.86" x 0.94" / 115.1 x 98 x 24 mm

• The LOC24 is a 4-channel line-output converter designed for durability and ease of integration when adding an aftermarket amplifier.
• It features single dial, precision matched, stereo & level gain adjustment, and selectable load input impedance for flexible compatibility.
• The converter supports up to 40 volts RMS high-level input sensitivity and up to 9.5 volts RMS low-level RCA output.
• Its selectable GND / ISO / 200Ω ground isolation and bass boost of 0-12dB ensure optimal performance and system noise prevention.
• With dimensions of 4.53" x 3.86" x 0.94", it is compact and easy to install in various audio setups.
• Manufactured by Diamond Audio, it delivers premium audio solutions, specializing in high-performance car, marine, and motorsports audio equipment.
